Employee Face Recognition Attendance Machine Temperature Detection
Employee Face Attendance Machine Fingerprint Temperature Detection Scanner
TM-AI03FT is a Linux Based Visible Light Facial and fingerprint Recognition Temperature Measurement Device
Enhanced Visible Light Facial Recognition with 6 pieces of brighten LED. Support WDR with good performance under strong light, dark light and backlight environment. Multiple verification methods: Face/Fingerprint/Card/Password. Built-in ID reader of 125KHz, Optional 13.56MHz IC(MF) card. Professional web based management software. Recognition distance: 0.5-2.5 meters.
Face Recognition Temperature Scanner Features:
- Support multi-person face recognition with 5 persons at the same time (You can set in the menu to choose a single person or multi-person recognition)
- Support WDR (wide dynamic range), with good performance under strong light, dark light, and backlight environment
- Support mask detection (you can set in machine Yes/No)
- Support capture stranger's face if he appears in the camera
- Display user enrolled photo when verified face
- Support set face recognition distance: close (around 0.8m), middle (around 1.5m), far (around 2~3m)
- Support lock screen: After the device screen does not uses, the screen will lock. Users have to unlock the screen by using fingerprint detection, activate the screen for face recognition detection.
- Support match in server
- Support temperature detection
Face Recognition Temperature Scanner Specifications
| Temperature Detection | Support |
| Temperature Detection Method | Melexis (90614DCI) Single point temperature measurement Sensor |
| Temperature Detection Range | 0.5 meters (Detection error: 0.5 ℃ ) |
| CPU Processor | 1.2G Dual-Core ARM Cortex-A7 |
| NPU Processor | NPU: 0.6T |
| RAM | 256MB DDR3L |
| ROM | 4GB eMMC |
| Cabinet raw material | ABS case |
| Camera | Dual (IMX307) Cameras with 1/2.8" CMOS; Lens: 6 mm 2M Pixel HD Color; 2.1M (GC2145) infrared camera |
| LED | LED Double high power infrared light |
| Display | 5'' HD IPS Screen |
| Resolution | 720*1280 |
| Dimension | 154*152*22mm |
| Exposure compensation | Under the strong light, sun light and back light, exposure compensation will be automatically |
| Communication | Support LAN/wifi/u disk connection, support CS desktop version software, real-time data upload, cloud websocket |
| FRR | <0.1% |
| FAR | <0.001% |
| Power supply | DC 12V, 1A~5A |
| Operating system | LINUX 3.10 |
| Language | 20 country of languages |
| Face capacity | 5,000 |
| Card capacity | 15,000 |
| Finger capacity | 10,000 |
| Record Capacity | 500,000 |
| Identification stylel | Face, Finger,ID Card, PIN or combination |
| Access Control | Interface output: Lock control , doorbell, U-Disk, Wiegand, relay, alarm output.
Interface input: Exit button, Wiegand, fire linkage. Compatible with all our fingerprint machines |
| Identification Mode | 1:1, 1:N |
| Face recognition time | <0.2S |
| Intelligent function | Live face detection |
| Detection range | 0.5-2.5m |
| Magnetic door | support |
| Alarm output | 1 set |
| WG | 1 set WG In, out |
| Waterproof rating | NIL |
| Installation Environment | Indoor |
| Desktop Software | AAS Version 6.8 |
| Cloud Software | www.yunatt.com:82 |
| SDK | Free SDK |
Face Recognition Temperature Scanner FAQ?
Q1: Are you a manufacturer or a trade company?
Reply : Shenzhen Union Timmy Technology Co., Ltd. is one of the leading manufacturers and exporters. We are enjoying an excellent reputation through 20 years’ production experience of time attendance in China.
Q2: How many days can we get the products if placed purchase order?
Reply : In regularly, 1-3 working days for Sample and ready stock;
15 working days for production order after receiving order deposit.
Q3: Which payment method are acceptable?
Reply: T/T, PayPal, and L/C are available.
Q4: When did your company formed?
Reply : Since year 2000, the founders of Shenzhen Union Timmy Technology Co., Ltd. (Timmy Technology) have been striving for independent research and development of biometric verification algorithms, vertical three roller gates, access control system, one-card management system and the production of biometric verification SDK which was initially widely applied in PC security, time attendance and identity authentication fields.
Q5: Can I get some samples?
Reply: We are honored to offer samples for your evaluation.
Q6: Can we print Logo for OEM?
Reply: Logo printed and client customization are our expertise for ordering at MOQ in 100pcs.
Q7: How does your factory do regarding QC?
Reply: Quality check is our first priority for our customers without any careless.
Furthermore, Timmy Technology has been recognized as a "National High-tech Enterprise" for 3 consecutive years, passed ISO9001 certification, and the products have passed FCC/CE/ROHS certification, etc
Should you have any inquiry, feel free to contact us
